We could offer the customization according to your demands or design paper.
Origin：XiangRui-Prosper, China
LED Lamp Head Parameters
Housing Material: High-quality die-cast aeronautical aluminum alloy
Protection Rating: IP66 or higher
Single Lamp Power Range: 30W–200W
Rated Voltage: AC85–265V municipal power; optional DC12V/24V for solar street light
LED Chips: Philips SMD3030 / SMD5050 high brightness LED chips
LED Driver: Philips / MeanWell / XiangRui-Prosper constant current driver
Luminous Efficiency: 120–200 Lm/W
Power Conversion Efficiency: >95%
Color Temperature: 3000K–6500K (Warm White / Natural White / Cool White)
Operating Temperature: -40°C ~ +50°C
LED Service Lifespan: 50,000+ hours
Light Pole Parameters
Pole Material: Hot rolled steel, optional Q235A / Q345B / A36 / ST52
Height Range: 3m–15m
Pole Wall Thickness: 1.8mm–8mm
Welding Method: Automatic submerged arc welding, seamless & smooth weld
Anti-Corrosion Treatment: Internal & external hot-dip galvanization, zinc coating thickness ≥86μm
Surface Finish: Outdoor electrostatic powder spraying, coating thickness ≥100μm
Wind Resistance Capacity: ≥36.9 m/s
Earthquake Resistance: Grade 8
Pole Shape: Tapered octagonal pole / tapered square pole / equal-diameter round pole
Surface Color: Customizable per project demand
| Quantity: | |
|---|---|
xiangrui
Pricing
1. Select street light style & model.
2. Provide full specifications: pole height, single lamp wattage, AC mains or DC solar type, customized color & bracket demands.
3. Get official customized quotation with technical datasheet.
If you are unsure of specific requirements, contact us and share your application environment (urban main road / village road / industrial park road), road width, local climate and brightness standard, we will provide matched dual-arm street light lighting solution.
Customization Services
We support full customization of dual-arm street lights based on your project drawings and technical demands. We balance structural stability, beautiful appearance and high energy efficiency, with independent heat dissipation, lightning surge protection and professional road asymmetric optical design, low light decay and ultra-low later maintenance cost.
Source Manufacturer
 |   | |
 |  |  |
